Quick answer: A pilot light is a small gas flame that lights the main burner in a furnace, water heater or fireplace. Older furnaces used a standing pilot that burns nonstop. Most new gas furnaces have no standing pilot and light the burner electronically instead. A healthy pilot flame is steady and blue; a yellow flame or a pilot that keeps going out needs a licensed gas technician.

Many homes in Markham, Richmond Hill and across the GTA still have a gas appliance with a pilot light, often an older furnace, a tank water heater or a gas fireplace. When the heat stops on a cold night, the pilot is the first thing people ask about. This guide explains what it does, how it differs from newer ignition systems, what a normal flame looks like, why it goes out and when to stop repairing an old system.
What is a pilot light and what does it do?
A pilot light is a small flame, fed by its own tiny gas supply, that sits beside the main burner. When your thermostat calls for heat, the control opens the main gas valve and the pilot flame lights the gas at the burner.
It also plays a safety role. A heat-activated device, usually a thermocouple, proves the flame is there. If the pilot light goes out, that device shuts off the gas supply so unburned gas does not flow into the appliance.
You will still find pilots in:
- Older furnaces and boilers. Units built before electronic ignition became standard.
- Tank-style water heaters. Many conventional gas models still use one.
- Gas fireplaces and inserts. Older models often have a standing pilot; newer ones usually light it only when needed.
Do new furnaces have pilot lights?
In most cases, no. Gas furnaces sold today light the burner electronically, with a hot surface igniter that glows red hot or a spark that lights a small pilot only for each heating cycle. Training material for gas technicians notes that intermittent pilots have replaced most standing pilots, because a flame that burns all the time lowers efficiency.
Under Canada’s Energy Efficiency Regulations, most gas furnaces manufactured on or after July 3, 2019 must reach at least 95% AFUE, the high-efficiency condensing category. A furnace installed in the last several years almost certainly has no standing pilot light. If you can see a small flame through the sight glass when the heat is off, you have a standing pilot. Do not remove burner covers to check.
Standing pilot vs intermittent pilot vs hot surface ignition
| Type | How it lights the burner | Burns gas between cycles? | Where you usually see it |
|---|---|---|---|
| Standing (continuous) pilot | A small flame stays lit all the time and lights the burner on every call for heat | Yes | Older furnaces and boilers, many tank water heaters, older fireplaces |
| Intermittent pilot | A spark lights the pilot only when heat is needed, then the pilot goes out after the cycle | No | Many boilers, newer gas fireplaces, some furnaces |
| Hot surface ignition | An igniter glows red hot and lights the burner gas directly, with no pilot | No | Most modern gas furnaces |
If a newer furnace will not light, the igniter is a common suspect. Read what causes a bad furnace ignitor.
Thermocouple vs flame sensor: what keeps the gas safe?
Thermocouple (standing pilot systems)
A thermocouple is a metal probe that sits in the pilot flame. Heat from the flame produces a tiny electrical signal that holds the gas valve open. If the pilot light goes out, the signal fades and the valve closes. Many fireplaces use a thermopile, a larger version of the same idea.
Flame sensor (electronic ignition furnaces)
In a furnace with electronic ignition, a thin metal rod called a flame sensor sits in the burner flame and confirms the burners actually lit. If it cannot prove a flame, the control shuts the gas valve within seconds. A dirty sensor is a common reason a furnace lights, runs briefly and shuts off. See what you should know about a dirty flame sensor.
Both parts live inside the burner compartment of a gas appliance. Testing, cleaning or replacing them is work for a licensed gas technician, not a DIY job.
What colour should a pilot light flame be?
A healthy pilot light flame is steady, crisp and blue, and it sits firmly against the thermocouple or burner it is meant to heat. Public safety guidance lists a yellow flame in a natural gas appliance, instead of a blue one, as a possible carbon monoxide (CO) warning sign.
Signs that need a technician
- Yellow or orange flame. This can point to incomplete combustion, which can produce CO.
- Lazy, wavering or lifting flame. A flame that floats or pulls away from the burner is not burning properly.
- A pilot that keeps going out. This is also listed among CO warning signs.
- Soot around the appliance or vent. Black marks mean poor combustion.
- Stale air or heavy window moisture. These can also signal a venting problem.
If you notice any of these, turn the appliance off at the thermostat or switch if it is safe to do so, and book a licensed technician.
Carbon monoxide alarms in Ontario
The province requires CO alarms next to each sleeping area in homes that have a fuel-burning appliance, a fireplace or an attached garage. Since January 1, 2026, the Ontario Fire Code also requires an alarm on every storey, including storeys without bedrooms (see Ontario’s carbon monoxide safety page). If a CO alarm sounds, get everyone outside and call 911 from outside. CO symptoms can include headaches, nausea, dizziness and confusion, so see a doctor if symptoms persist.
Why does a pilot light keep going out?
A pilot that will not stay lit is a symptom, not the problem itself. Common causes:
- A worn or weak thermocouple. It can no longer produce enough signal to hold the gas valve open.
- A dirty or partly blocked pilot opening. Debris can shrink the flame until it no longer heats the thermocouple.
- Drafts. Air moving near the appliance or down the vent can blow out a small flame.
- Venting or combustion air problems. A blocked vent can starve the flame of oxygen. In winter, check that outdoor vents are clear, as covered in our guide to a furnace vent blocked by snow.
- A faulty gas valve or supply issue. Problems with the control valve or gas pressure need professional diagnosis.
What you can safely do
If you want to relight a pilot light, follow the instructions on the appliance label exactly, or call a licensed technician. If it goes out again, stop. Repeated relighting can hide a combustion fault.
If you smell gas (a rotten egg odour), do not try to relight anything and do not use light switches. Leave the home, then call Enbridge Gas at 1-866-763-5427 or 911 from outside.
Does a standing pilot light waste gas?
Yes, a standing pilot light uses some gas around the clock, including through the summer when no heat is needed. That continuous use is the main reason the industry moved to intermittent pilots and hot surface ignition. The cost depends on the appliance and your gas rates, so be wary of any single number you see online.
Gas fireplaces are a good example of the shift. Under federal rules for gas fireplaces made on or after January 1, 2020, units must be able to put the pilot out automatically once the main burner is lit, and if you switch to continuous pilot, it cannot stay on for more than seven days (see the Natural Resources Canada gas fireplace requirements). Many owners of older fireplaces turn the pilot light off for the summer, following their manual. Read whether it is safe to leave a gas fireplace on overnight, or ask about fireplace service and installation.
When should you replace a furnace with a pilot light?
A standing pilot alone is not a reason to replace a furnace that is safe and working. Compare repair and replacement when:
- The pilot or its safety parts fail more than once in a season.
- A technician finds combustion, venting or heat exchanger concerns.
- Your heating bills keep rising and the furnace is clearly near the end of its life.
A modern high-efficiency furnace lights itself electronically and wastes far less heat up the vent. If you are weighing options, Aire One offers a free Total Home Assessment, financing and a 10-year worry-free warranty on furnace replacement in Markham.
Whatever you have, the Technical Standards and Safety Authority (TSSA) recommends having all fuel-burning appliances inspected every year by a TSSA-registered fuel contractor and keeping certified CO alarms tested. Gas appliance work in Ontario must be done by a TSSA-registered contractor using licensed gas technicians.
Frequently asked questions
Do all gas furnaces have a pilot light?
No. Most gas furnaces sold today use electronic ignition, either a hot surface igniter or an intermittent spark pilot, so no flame burns between heating cycles. Standing pilots are mostly found on older appliances.
Is it safe to leave a pilot light on?
A standing pilot is designed to stay lit, and it is generally safe when the appliance is properly vented, maintained and inspected each year by a licensed gas technician. Keep working CO alarms near sleeping areas and on every storey. For a fireplace, follow the manufacturer manual.
What does a yellow pilot flame mean?
A yellow or orange flame can mean the gas is not burning completely, which can produce carbon monoxide. Turn the appliance off if you can do so safely and have a licensed technician inspect it. A normal pilot flame is steady and blue.
Can I relight a pilot light myself?
Only if you follow the instructions on the appliance label exactly. Otherwise, call a licensed technician. If the pilot goes out again, stop and book service. If you smell gas, leave the home and call Enbridge Gas at 1-866-763-5427 or 911 from outside.
What replaced the pilot in newer furnaces?
Most newer furnaces use a hot surface igniter to light the burners and a flame sensor to confirm the flame. If no flame is detected, the gas valve closes.
How often should a gas furnace or fireplace be inspected?
Every year. The TSSA recommends annual inspection of all fuel-burning appliances by a TSSA-registered fuel contractor.
